Where FR protection is needed but hi-vis is not, the FR503 is a plain black or navy coverall in inherent Modaflame 280gsm. Every component is metal free, which matters where metal studs could add arc or spark risk.
It is certified to EN ISO 11612, EN ISO 11611 Class 1, EN 1149-5 and EN 13034 Type 6. Arc rating is ELIM 6.4 cal/cm² and EBT 6.8 cal/cm² (APC 1), and ATPV 8.4 cal/cm² under ASTM F1959. It is not rated to EN ISO 20471 or EN 343.
Sizes XS to 4XL.
Features
- Metal-free components
- Stretch panelling
- Back ventilation
- Adjustable waistband
- Pre-bent sleeves and adjustable cuffs
- Embroidered FR logos
- Multiple pockets
Standards
- EN ISO 11612 (A1+A2, B1, C1, F1)
- EN ISO 11611 Class 1 (A1+A2), for less hazardous welding than Class 2
- EN 1149-5
- EN 61482-1-1 (ELIM 6.4 cal/cm², EBT 6.8 cal/cm²)
- EN 61482-1-2 APC 1
- ASTM F1959/F1959M-12 (ATPV 8.4 cal/cm², HAF 75.8%)
- EN 13034 Type 6
- Not rated to EN ISO 20471 or EN 343
- Testing and certification: SATRA Technology Europe Ltd, certificate 2777/25415-01/E00-00
Materials
Inherent Modaflame, 280gsm.
Care
Follow the care label in the garment. Fabric softener and bleach based products can degrade flame resistant fibres, so leave them out. Retire the coverall if it is visibly damaged or fails a wash care check.
